Stainless Steel Wire Mesh

  • Weave Style:Plain Weave
  • Standard width:1m-8m
  • Customise acceptable
  • Free sample
  • Product description: Stainless steel wire mesh most used in mine, petroleum, chemical, foodstuff, pharmaceutical, mechanical industries. resistant acid and alkali , high temperature resistant, pull and wear resistance
  • INQUIRY

1.Material:ss201,202,302, 304, 304L,310, 316, 316L,321 etc

2.Application:most used in mine, petroleum, chemical, foodstuff, pharmaceutical, mechanical industries.

3.Properties: resistant acid and alkali , high temperature resistant, pull and wear resistance

4.Specification of Stainless steel wire mesh

mesh/inch

wire gauge

aperture

opening area

weight
/100 m2feet

inch

millimeter

inch

millimeter

1x1

.080

2.03

.920

23.37

84.6

41.1

2X2

.063

1.60

.437

11.10

76.4

51.2

3X3

.054

1.37

.279

7.09

70.1

56.7

4X4

.063

1.60

.187

4.75

56.0

104.8

4X4

.047

1.19

.203

5.16

65.9

57.6

5X5

.041

1.04

.159

4.04

63.2

54.9

6X6

.035

.89

.132

3.35

62.7

48.1

8X8

.028

.71

.097

2.46

60.2

41.1

10X10

.025

.64

.075

1.91

56.3

41.2

12X12

.023

.584

.060

1.52

51.8

42.2

14X14

.020

.508

.051

1.30

51.0

37.2

16X16

.018

.457

.0445

1.13

50.7

34.5

18X18

.017

.432

.0386

.98

48.3

34.8

20X20

.016

.406

.0340

.86

46.2

34.4

30X30

.009

.229

.0243

.62

53.1

16.1

40X40

.010

.254

.0150

.38

36.0

27.6

50X50

.008

.203

.0120

.31

36.0

22.1

60X60

.007

.178

.0097

.25

33.9

20.4

70X70

.0065

.165

.0078

.20

29.8

20.8

80X80

.0055

.140

.0070

.18

31.4

16.9

100X100

.004

.102

.0060

.15

36.0

11.0

110X110

.0040

.1016

.0051

.1295

30.7

12.4

120X120

.0037

.0940

.0064

.1168

30.7

11.6

150X150

.0026

.0660

.0041

.1041

37.4

7.1

160X160

.0025

.0635

.0038

.0965

36.4

5.94

180X180

.0023

.0584

.0033

.0838

34.7

6.7

200X200

.0021

.0533

.0029

.0737

33.6

6.2

250X250

.0016

.0406

.0024

.0610

36.0

4.4

270X270

.0016

.0406

.0021

.0533

32.2

4.7

300X300

.0051

.0381

.0018

.0457

29.7

3.04

Stainless stell wire mesh
